Description

Size of host machine – W*L*H 140*170*176 mm (including rubber bumper) /130*170*170mm (excluding rubber bumper)
Weight – Host machine 2.18kg (including rubber bumper) / 1.82kg (excluding rubber bumper). Weight of battery 0.3kg
Applied In  – Trunk project
Alignment Method – Core core alignment, 6 motors
Fiber Cores – Single fiber
Applied fiber category – SM /MM/DS/NZDS
Diameter of fiber – 0.25-0.3mm / indoor cable
Fiber placed & cleaved length – Coating diameter 0.125-1mm / cleave length8-16mm
Splicing mode – Multiple splicing modes
Typical Splice loss – 0.01dB-0.05dB
Return loss – > = 60dB
Lighting – 3 high-power LED white light
